Epson SureColor P20000 Standard Edition Printer

The Art of Performance.

The all-new 44” Epson SureColor P10000 and 64” Epson SureColor P20000 are the successors to one of the most widely used fine art printers ever developed – the Epson Stylus^® Pro 11880.

Designed for high-production photographic, fine art and indoor display graphics printing, we’ve incorporated newly-developed imaging technologies – including an all-new high-performance 2.6” wide Epson PrecisionCore^® MicroTFP^® print head. Along with an all-new Epson UltraChrome PRO nine-color pigmented ink set – including four levels of gray – the all-new SureColor P10000 and SureColor P20000 are the ultimate production tools for the demanding requirements of high-production color and black-and-white fine art printmaking.

Including advanced media handling options from cut sheet to roll, from plain papers to photographic, fine art, and even 1.5 mm thick poster boards, the new Epson SureColor P10000 and SureColor P20000 redefine the state of the art in wide format, high-production photographic imaging applications.

More Info?

Model: SCP20000SE

Find Ink

REPLACEMENT PRODUCT :

SureColor P20570 64-Inch Professional Printer

Model: View Main Product Page Learn More

Overview

UltraChrome® Pro Inks

Next Generation Pigment Ink Technology — Introducing all new pigments for outstanding color performance and Improved Resin Encapsulation Technology for superior gloss uniformity
Improved Black Density — Photo Black pigment 1.5 times denser than the previous generation ink set, along with significant improvement to overall contrast ratio and optical clarity
Significant Print Permanence Improvements — Featuring completely reformulated pigment technology for improved print permanence, and up to twice the overall print permanence versus our previous generation ink set¹
Extreme Color Balance — 4 levels of black, featuring an all-new dark gray for rendering superb gray balance through the entire tonal range of B&W and color prints at any production speed

PrecisionCore® microTFP Printhead

Design for Production — 2.6 inch tall printhead with 800 nozzles per color, 8000 high performance nozzles in all
Robust Engineering — Single head configuration designed for maximum quality and reliability in demanding high-speed environments
Epson Precision Dot — Delivers best-in-class continuous tone image quality at production level print speeds

Printer Applications²

Ultra-Fast Drafts — Print at up to 1,311 sq ft/hour (1 pass) on plain paper when speed is the critical factor
High-Speed Poster Printing — For high-speed production on various coated media types, the 411 sq ft/hour (4 pass) and 273 sq ft/hr (6 pass) modes provide highly sellable output
Indoor Display Graphics — The 273 sq ft/hour mode (6 pass) on semigloss or glossy media provides eye-catching photographic quality even up close
On-demand Photo & Fine Art — Start with 209 sq ft/hour (8 pass) or move up in quality to 104 sq ft/hour (16 pass) for best-in class fine art production printing. Perfect for use with Epson Signature Worthy Canvas, Fine Art and Photo media
Exhibition Quality Prints — Combine maximum quality 68 sq ft/hour (24 pass) with the highest quality Epson Legacy photo media for prints worthy of the world's most exclusive galleries and exhibitions

SURECOLOR P-SERIES RIP INFORMATION ►

What's in the box:

SureColor P20000 Printer
Printer Stand with Catch Basket
Spindle-free Roll Media Adaptors
Set of ten 110 ml initial ink cartridges
Internal Print Server 320GB
Ink Maintenance Tanks (installed)
AC Power Cable
User Guide Kit (Documentation and Warranty)
Software is provided via download

Specifications

Print:

Printing Technology: 10-channel, piezo inkjet print headMaximum Print Resolution: 2400 x 1200 dpi; 1200 x 1200 dpi; 1200 x 600 dpi; 600 x 600 dpi; 600 x 300 dpiPrint Speed: 16" x 20" prints from 1:47 to 3:17 Production is 2:09²Minimum Ink Droplet Size: Enhanced Variable Droplet Technology as small as 3.5 picolitersNozzle Configuration: Color and Monochrome; 800 nozzles x 10 channels

Ink:

Ink Type: Printer is designed for use with Epson cartridges only, not third-party cartridges or ink.Ink Palette: C, LC, VM, VLM, Y, LGY, GY, DGY, PK, MKInk Configuration: 10-ink, 9-colorReplacement Ink:

Photo Black T800100
Cyan T800200
Vivid Magenta T800300
Yellow T800400
Light Cyan T800500
Vivid Light Magenta T800600
Dark Gray T800700
Matte Black T800800
Gray T800900
Light Gray T800000

Fade Resistance / Print Longevity: UltraChrome PRO, our next-generation pigment ink technology, is independently rated by Wilhelm Research for up to 200 years for color prints and up to 400 years for black-and-white prints¹

General:

Operating Systems: Apple macOS^® 10.13.x-10.12.x, OS X^®: 10.11x-10.7x⁶
Microsoft^® Windows^®: 10, 8.1, 7 (32-bit, 64-bit)⁶Temperature: Storage: -4° to 104°F (-20° to 40°C)Humidity: Storage: 5 to 85% (no condensation)Sound Level: Sound Power Level: approx. 65.3 dB(A)Dimensions: Basket Open: 95.1" x 38.4" x 45.1" (2415 x 980 x 1168 mm)Weight: 377 lbs (171 kg)Safety Approvals: Safety Standards: UL605950-01, CAN/CSA C22.2 No. 60950-1 EMC FCC part 15 subpart B class A, CAN/CSA-CEI/IEC CISPR22 class A, AS/NZS CISPR 22 class ACountry of Origin: ChinaWarranty: Optional Epson SureColor P-Series Extended service plans available for purchase.

Ink Supply System:

Ink Supply Fill Volume: Cartridge fill volume: 700 ml each x 10 colors totalInk Shelf Life: 2 years from printed production date or 6 months after open

Printable Area and Accuracy:

Maximum Paper Width: 64"Minimum Cut-sheet Size: Minimum recommended cut-sheet: 13" x 19"Minimum Paper Width: 10"Maximum Printable Width: 63.75” in standard print modeLine Accuracy: +/- .26mm minimumMaximum Printable Length: As allowed by the Epson MAC and PC printer driver. Application, version of application and Operating System version may limit maximum length.

Sheet Media Handling:

Sheet Loading: Top-loading if less than .5mm thickThickness: 0.8mm to 1.5mmSingle Sheet, Top-loading: Up to 44" wideBorderFree Print Widths: 10", 11.8", 12.95", 16", 17", 20", 23", 24", 28.86", 29", 33.11", 36", 40.55”, 44”, 50” 54” and 60”Left/Right Margins: 3mm each side; 6mm or 0.24" totalTop/Bottom Margins: 15mm / 15mm (with centering)

Printer Details:

Printer Language: Epson Professional Photographic Drivers standard; optional internal Adobe® Postscript® 3™ print server¹Interfaces: 1000Base-T Ethernet (1 port)

Power:

Rated Voltage: AC 110 – 240 VRated Current: 0.208333333333333Power Consumption: Sleep Mode: approx. 2.8 W (1000 BaseT Ethernet in Standby Mode)

See Full Specs Hide Full Specs

Print All Specs

Accessories

Accessories

Ink

Notes:

* Price is MSRP before any applicable rebates. Reseller prices may vary. All prices are in U.S. Dollars.

¹ Ink lightfastness rating based on accelerated testing of prints on specialty media, displayed indoors, under glass. Actual print stability will vary according to media, printed image, display conditions, light intensity, humidity and atmospheric conditions. Epson does not guarantee longevity of prints. For maximum print life, display all prints under glass or lamination or properly store them. Visit www.wilhelm-research.com for the latest information.

² Print times are based upon print engine speeds only. Total throughput depends upon front-end driver/RIP, file size, printing resolution, ink coverage, network speed, etc. Normal is for prints imaged using 1200 x 600 High-speed Mode.

³ Cartridge yields vary considerably based on images printed, print settings, paper type, frequency of use and temperature. For print quality, a variable amount of ink remains in the cartridge after the “replace cartridge” indicator comes on. The printer ships with full cartridges and part of the ink from the first cartridges is used for priming the printer.

⁴ High-volume cutting of canvas and heavy media stocks may require frequent cutter replacement.

⁵ Allowed by printer driver for Mac® and PC. Application used, version of application and operating system version may limit maximum length.

⁶ For the latest drivers, visit www.epson.com/support
