Epson EpiqVision® Ultra LS800
Ultra Short-Throw Laser Projector*

The Epic Entertainment Experience.

Go Epic. A 120-inch projector display featuring a basketball player. Projector does not enable 3d viewing.

Epson EpiqVision Ultra LS800

Whether you're watching live sports, gaming on the latest generation of consoles, or streaming your favorite movie, the Epson EpiqVision Ultra LS800 delivers an epic big screen experience that will simply amaze you.

Cutting-Edge Ultra Short-Throw Laser Projection from Epson.

Epson designed an all-new multi-element precision glass ultra short-throw lens technology, allowing for a modern case design that drastically reduces the throw distance.

This allows the EpiqVision Ultra LS800 to beautifully sit on normal audio video cabinets and other furniture while displaying a sharp picture up to 120".

EpiqVision Ultra LS800 can project up to 100-inch just 17.3-inch from the wall, and up to 120-inch just 20.2-inch from the wall.

Markup of a football play

Bring the Sportsbook Experience Home.

With a display up to 120 inches, watching live sports is truly an epic event.

And for Fantasy League & Sports Betting – having the ability to watch multiple games on the same screen – delivers a whole new level of excitement.

Unless you're on the field live – nothing else even comes close.

Multiple game viewing requires 3rd party apps or 3rd party providers' content delivery functionality. Additional fees may apply.


Advanced pixel-shifting technology precisely controls three individual high-definition LCD chips to produce an exceptionally sharp 4K experience without sacrificing brightness.

This is how the 4K projection experience was meant to be.

Designed for 4K ContentDesigned for 4K Content
Modern Thin Bezel DesignModern Thin Bezel Design
 Ambient Light Rejecting Screen Ambient Light Rejecting Screen
Glare-free Ultra-wide Viewing AngleGlare‑free Ultra‑wide Viewing Angle
Optical Picture Brightness & Enhancement TechnologyOptical Picture Brightness & Enhancement Technology
16:9 Aspect Ratio 16:9 Aspect Ratio

The Latest Epson Technology.

3LCD logo. Action shot of a soccer player on a projection screen.

True 3-Chip 3LCD Projection

Unique Epson technology that takes full advantage of the projectors brightness to produce exceptional color performance without any distracting rain-bowing or other color brightness issues seen with other projection technologies.

Projection of a basketball player dunking the ball, demonstrating the result of advanced digital picture processing. Images simulated.

Advanced Digital Picture Processing

Realtime 10-bit analog-to-digital video processing for smooth tonal transitions, while helping to eliminate banding, blocking, and other compression artifacts from the final visual performance. This powerful processing technology faithfully reproduces the source material the way it was intended to be shown.

An artistic projection of a woman covered in paint, demonstrating the color difference of HDR. Disclaimer: Images simulated.

10-Bit HDR Color Processing

Full 10-bit HDR color processing accepting 100% of the HDR source. When combined with the extreme brightness of 4,000 lumens2, HDR content is faithfully reproduced for an exceptional visual performance.

Awesome for Gaming.

If you're a serious console or PC gamer, the EpiqVision Ultra LS800 will take your gaming experience to a new level of immersion.

Imagine gaming on a 100" or 120" 4K PRO-UHD with HDR display with input lag times below 20ms. The experience is truly epic.

Gamers in a living room playing a fantasy game on a large projected display.

An Exceptional Home Theater Experience.

When the lights are off, the visual performance of the EpiqVision Ultra LS800 is simply epic. The picture quality and color performance is exceptional especially with HDR content. You may never go to the theater again it's that good.

Android TV. Chromecast built-in.

Included Android TV3 operating system with a simple-to-use remote including voice search with built-in Google Assistant. Watch all your favorite streaming channels including HBO, Disney +, YouTube, Hulu, ESPN and more. Even stream live TV with apps like YouTube TV.4

Image Gallery

What are the Press Saying?

"We quickly connected the projector to YouTube via its built-in menu and put up NFL highlights. Honestly, it was like being in our own private screening room."


Sound & Vision Logo

"At CEDIA, the standout UST demo belonged to Epson and its new EpiqVision LS800 projector, a new model that offers several advantages over its predecessor, the LS500. It’s my first hands-on experience with one and what I saw left a strong positive impression."


Dealer Scope Logo

"It has a laser-array light source which delivers deep blacks and rich colors, and can offer 4K HDR viewing with a 60 Hz refresh rate when displayed up to 150-in. And a whopping 4,000 lumens of color brightness is packed into the projector’s tech, creating an accurate and bright color display."


Technical Specifications

Epson EpiqVision Ultra LS800 Laser Projector

Case Color

White or Black

Dynamic Contrast Ratio

Up to 2,500,000:1

Native Refresh Rate

4K/60 Hz

Noise Level

Up to 32 dB


Yamaha DSP technology, AudioEngineTM with FR-PortTM speakers

Brightness (White & Color)

4,000 Lumens in White3

4,000 Lumens in Color3



Real-time 10-bit video processing.

Projection Technology

Ultra Short-Throw Laser Array

True Laser Diode with 20,000 hours of life6


27.4" x 6.2" x 13.4". (W x H x D)


27.6 lbs.


Full 10-Bit HDR processing with 16 step adjustments

HLG supported

Input Lag

Less than 20 milliseconds

Ideal for matching with gaming consoles and PC gaming

Main Connectivity

18 Gbps HDMI 2.0 x 3

One HDMI port is ARC compatible when using the internal Android TV interface

All HDMI ports are HDCP 2.3 compatible

Optional Connectivity

S/PDIF Optical Out x1

Mini Stereo Out x1

USB Type A x1 (for power only 5V/2A)

Wireless - WiFi 5 (for Built-in Android TV OS)

Bluetooth 5.0 (for external sound solutions via Built-in Android TV OS)

Base Projected Image Control

Manual Focus Adjustment

Epson Setting Assistant App

Multi-point Alignment Adjustment

White Balance Optimization

Adaptive Light Output Function

Flexible Picture

Questions & Answers

Directly from the Development Team
Just like you do with any standard TV. The Epson EpiqVision Ultra LS800 comes with two 18 Gbps HDMI 2.0 input ports on the back and one 18 Gbps HDMI 2.0 input port behind the front cover.
Yes. We designed the 100-Inch and 120-Inch screen to optimize resolution and brightness – while minimizing the effect of ambient room lighting. Our Epson Silverflex Ultra ALR Screen are really amazing technology.
Yes. In fact we’ve partnered with many Best Buy locations throughout the U.S. You can locate the Best Buy demo center nearest you on this website. In addition, Epson has Professional Home Theater Installers all over the U.S. They also have the ability to provide you a demo.

The EpiqVision Ultra LS800 Laser Projector and SilverFlex Ultra ALR Screens ship in their own separate boxes.

Epson still offers a significant discount on the SilverFlex Ultra ALR Displays when purchased with an EpiqVision Ultra LS800 Laser Projector. See your retailer for more information.

Yes. The complete solution is designed for customer installation. And, all the required hardware comes in the box. Search YouTube for install videos.

However, if you're not very technical, ask your reseller for installation options through them. They may charge for installation, so check with them for the latest pricing.

The EpiqVision Ultra LS800 Laser Projector comes with a custom-designed 2.1 audio system by Yamaha. For a built-in speaker, its pretty awesome.

However, for a truly epic audio experience to match the big-screen display, and external audio system is recommended.

No. The screen requires no power or connections from the projector. It simply hangs on your wall and is relatively light.

The 100" screen weighs 24.3 lbs.

The 120" screen weighs 28.7 lbs.

Yes. In fact, many of us at Epson are serious gamers.

My current Sony® PS5 and MicrosoftTM Xbox Series X see this display as 4K with HDR at a full 60 frames per second. The recorded Input Lag times are an impressive 16.7 milliseconds.

And yes, it's awesome gaming on a display this big.

No. The EpiqVision Ultra LS800 Laser Projector was designed to be placed below and centered with the Epson SilverFlex Ultra ALR Screen or third-party ALR screens.

Yes. One of the breakthroughs from Epson is our newest Ultra Short-Throw Laser Array Technology. When combined with a special screen (like our SilverFlex Ultra ALR screen), the overall brightness of the picture is incredible and performs great even in bright rooms.

Search YouTube for customers and resellers that are demoing the product, or find a Best Buy store nearest you that is showcasing the product in their demo room. It's really amazing technology.

Epson designed this product for people who really want a larger TV experience in their homes. Today's TVs max-out at about 86".

Of course, the latest generation of OLED and QLED's have better color and black performance, but the Epson EpiqVision Ultra LS800 Ultra Short-Throw Laser Projector has very impressive performance as well.

And, when this level of picture performance is being displayed at 100" or 120" – the immersive experience is simply epic. Nothing else even comes close.

Epson worked closely with Alphabet to design a complete Android TV OS for the EpiqVision Ultra LS800 Laser Projector. So, everything you'd expect from any Android TV based system is supported.

Of course, you can ignore this and install your own streaming solution if you want.

You really have to see it for yourself. I can say that Epson’s latest 4K PRO-UHD technology is extremely impressive. And delivers probably the best 4K HDR home theater experience of anything else in its class.

Since most live TV content is 720p or 1080p, 4K PRO-UHD has processing tech that upscales to 4K PRO-UHD. The results are impressive. And because this is one of the brightness Laser Array Projectors on the market, the HDR performance is really something to see. If you’re crazy about seeing every little detail the content has to offer – like we are at Epson – you’ll be impressed with this technology.

For the most part yes, this is a new technology. What makes this system really work is that Epson developed a 3-chip 3LCD ultra short-throw laser-array projector with 4,000 lumens for both color and white brightness. This level of color and white brightness is exceptional and un-matched within the industry.

And when you combine this level of projection performance with a specifically designed ambient light rejecting screen, the results are amazing. Three years ago when Epson set-out to design the projector and screen to work together, a new-type of television experience was created.

1 4K Resolution Enhancement Technology shifts each pixel to produce an image on screen, up to the stated specification.

2 Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118.

3 In order to use the Android TV, the device must be configured on a network via a wireless connection of 5 Mbps or faster.

4 Requires wireless network connection of 5 Mbps or faster. Some apps require paid subscriptions.

5 Visit the Google® Chromecast website for the latest smart device and computer OS support.

6 Based on an estimated projector life of 20,000 hours when used in Normal Mode. Actual hours may vary depending on mode and usage environment. The projector comes with a 2-year limited warranty.
