PowerLite 4750W WXGA 3LCD Projector

Installation Projector

The PowerLite 4750W offers high-definition image quality, a contrast ratio of 5,000:1, and 4200 lumens brightness. This helps project your important presentations and other displays in the best way possible. With its many intuitive installation features, using and configuring the projector is a breeze. Its wide zoom ratio of x2.0, plus Keystone correction and point and arc correction, make configuration in various positions quick and easy with no distorted or blurry image.

Model: V11H544020

Find Accessories Support

Overview

Up to 3x Brighter Colors and reliable performance — 3LCD, 3-chip technology*
One measurement of brightness is not enough — look for both high color brightness and high white brightness.
The PowerLite 4750W has:
Crisp, clear resolution — WXGA for incredible images
Lens shift — offers installation flexibility with a range ofmotion of up to ±70â”¬â–‘ vertical from center and ±38â”¬â–‘ horizontal from center; also features lens shift lock
Versatile connectivity — easily integrate with any system with HDMI and Display Port
Convenient remote management — remotely monitor and control presentations
Epson iProjection^TM — wirelessly display and control content from your iPhone®, iPad®, iPod touch®and Android™ devices²
Centered lens design — position the ceiling mount, screen and projector independently; the screen will align with the lens at the center of the projector
Faroudja DCDi Cinema technology and 2:2 pull-down — achieve exceptional video quality without introducing artifacts
3D stacking — using polarized filters and passive 3D glasses; or, double stack the projectors to display a 2D image, and get double the brightness
EasyMP Network Projection — easily present content over the network
Remote network monitoring and control — plus message broadcasting and built-in schedule functions
Split Screen³ — project two images (video or still) side-by-side from two different sources simultaneously
Digital connectivity — easily integrate your projectorwith any existing system, via HDMI and Display Port
Point and arc correction — adjust each side of an imagefor a perfectly rectangular image

IMPORTANT SAFETY INFORMATION ABOUT USAGE ENVIRONMENTS FOR MOUNTED PROJECTORS ►

What's in the box:

PowerLite 4750W Projector
Power cable
Computer cable (VGA)
Projector remote control with batteries
User manual CD
EasyMP® software CD
Quick Setup Sheet

Registration card
Password protection sticker
Lens lock screw

Specifications

Specifications Projector:

Projection System: High-aperture Epson 3-chip 3LCD technologyProjection Method: Front / rear / ceiling mountDriving Method: Epson Poly-silicon TFT Active MatrixPixel Number: 1,024,000 pixel (1280 x 800) x 3Color Brightness - Color Light Output: 4200 lumens¹White Brightness - White Light Output: 4200 lumens¹Aspect Ratio: Supports 4:3, 16:9, 16:10Resolution: 1280 x 800 (WXGA)Resize: 640 x 480, 800 x 600, 1280 x 1024, 1400 x 1050Lamp Type: 280 UHELamp Life:

Normal mode: Up to 4000 hours²
ECO mode: Up to 5000 hours²

Brightness Uniformity: 0.9Pixel Arrangement: Cross stripeThrow Ratio Range: 1.27 – 2.59Size - projected distance: 30" – 300"Keystone Correction:

Horizontal: ±30 degrees
Vertical: ±30 degrees

Contrast Ratio: High Brightness, Dynamic mode: 5000:1Color Processing: 10 bitColor Reproduction: Up to 1.07 billion colors

Effective Scanning Frequency Range:

Pixel Clock, Horizontal, Vertical:

Pixel Clock

13.5 MHz – 162 MHz (up to UXGA 60 Hz)

Horizontal

15 KHz – 92 KHz

Vertical

50 Hz – 85 Hz

General:

Temperature: 32° to 113° F (0° to 45° C)Humidity: Operation 20% - 80%, storage 10% - 90%Dimensions: 471 x 354 x 159 mm (width x depth x height)Weight: Weight with standard Lens 14.3 lbs.Security:

Security Cable Hole
Lens lock,
Kensington® lock provision

Projection Lens:

Type: Manual focus / ZoomF-number: 1.50 – 2.14Focal Length: 16.72 mm – 33.47 mmZoom: Manual, Factor: 1 - 2Zoom Ratio: Optical zoom 1.0x – 2.0xLens Shift:

Horizontal: ±38 degrees
Vertical: ±70 degrees

Connectivity Projector:

Standard Connectivity: RS-232C, Ethernet interface (100 Base-TX/10 Base-T), VGA input, VGA output, HDMI input, screen port, composite input, BNC input, S-Video input, Stereo mini-jack audio output, Stereo mini-jack (4x) audio input, Cinch audio input, LAN wireless IEEE 802.11b/g/n (optional)

Projector Details:

Display Performance:

NTSC: 480 line
PAL: 576 line

Color Modes: Dynamic, Photo, Presentation, sRGB, Theater, DICOM SIMInput Signal:

NTSC / NTSC4.43 / PAL / M-PAL / N-PAL / PAL60 / SECAM
480i / 576i / 480p / 576p / 720p / 1080i / 1080p
Pixel works: video chip
3D Y / C separation, noise reduction motion compensated
Interlace-Progressive conversion (2 – 2, 3 – 2 film detection)

Interfaces:

HDMI x 1
DisplayPort x 1
Computer: D-sub 15 pin x 1
Video 1: 5-BNC x 1
Video-2: RCA x 1
Composite video: BNC x 1
S-Video x 1
Audio-in: Mini stereo x 3
Audio-in: RCA (L&R) x 1
Network: RJ-45 x 1, 1,100 Mbps
USB Type-A x 1, Type-B x 1
Serial: RS-232c x 1
Hardwire remote jack x 1
Monitor-Out: D-sub 15 pin x 1

Speaker: 10 WSpecial Features: direct on/off, Quick Corner, six-axis color control, split screen featureFan Noise:

Normal mode: 38 dB
ECO mode: 32 dB

Projector Dimensions:

Including feet: 18.58" x 13.94" x 6.26" (W x D x H)Excluding feet and lens: 18.58" x 12.60" x 5.28" (W x D x H)

Remote Control:

Features: Power, source search selection, computer, video, A/V mute, freeze, user ID, auto, aspect, color mode, number, page up and down, E-zoom, volume, help, menu, enter, esc andpointer functionsOperating Distance: 49 ftOperating Angle:

Right / Left:

Front: ±60 degrees
Rear: ±30 degrees

Upper / Lower:

Front: ±20 degrees
Rear: +10 to +45 degrees

Power:

Power Supply Voltage: 100 – 240 V ±10%, 50/60 Hz ACRated Voltage: AC 100 V - 240 V, 50 Hz - 60 HzPower Consumption:

Normal mode: 409 W
ECO mode: 311 W
Communication on: 4.3 W standby
Communication off: 0.41 W standby

See Full Specs Hide Full Specs

Print All Specs

Accessories

Lamp

Support

Need Support?

Get the latest drivers, FAQs, manuals and more for your Epson product.

Go to Support

Notes:

*Color Brightness (Color Light Output) in brightest mode, measured by a third-party lab in accordance with IDMS 15.4. Color Brightness will vary depending on usage conditions. Top-selling Epson 3LCD projectors versus top-selling 1-chip DLP projectors based on PMA Research sales data for Dec. 2015 through Nov. 2016.

¹ Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118.

² Check your owner's manual to determine if a separate wireless LAN module must be purchased separately to enable wireless connection on your Epson projector. Epson projectors can be networked either through the Ethernet port on the projector (check model specifications for availability) or via a wireless connection. Not all Epson projectors are able to be networked. Availability varies depending on model.

³ Consult your user manual for input combinations.

Specifications Notes:
¹ Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118.

² Lamp life will vary depending upon mode selected, environmental conditions and usage. Lamp brightness decreases over time.
